Is the Daikin FIT a good heat pump for a Minnesota home?
A Daikin FIT heat pump suits tight Minnesota side yards: slim, side-discharge and rated by Daikin to -10°F, or -20°F for the cold-climate FIT Aurora. Most installs keep a furnace or electric backup, and a heat pump with us runs $7,500–$14,500 installed.
Key points
- The FIT is a ducted heat pump in a tall, shallow, side-discharge cabinet about a foot deep.
- Daikin lists heating down to -10°F for the FIT and -20°F for the FIT Aurora.
- The intake side can sit close to a wall; the discharge side needs open space.
- Daikin's manual calls for a stand, snow protection and a drain pan heater in cold, snowy places.
- Warranty terms depend on online registration within 60 days and on annual maintenance.
The FIT's selling point is its shape. It's a tall, shallow cabinet that pulls air in the back and blows it out the side, so it fits the narrow side yards between older Minneapolis and Saint Paul houses where a cube-style condenser would block the only walkway. The catch is clearance on the discharge side, and in Minnesota, snow.
What is the Daikin FIT heat pump?
Daikin sells two FIT heat pumps. Both use a variable-speed inverter compressor and R-32 refrigerant, both come in 2- to 5-ton sizes, and both are designed as communicating systems that work with Daikin indoor equipment and the Daikin One+ thermostat.
| Daikin FIT (DH7VS) | Daikin FIT Aurora (DH9VS) | |
|---|---|---|
| Efficiency | Up to 19.0 SEER2 and 8.8 HSPF2 | Up to 21.0 SEER2 and 10.0 HSPF2 |
| Heating operating range (spec sheet) | Down to -10°F | Down to -20°F |
| Cabinet (W × D × H) | About 37 in. wide, 12–13¾ in. deep, about 27–56 in. tall depending on size | 37 × 12 × about 56 in. at every size |
| Base | Optional drain pan heater | Hot-gas base pan |
The FIT Aurora is ENERGY STAR cold-climate certified, and Daikin says it met the requirements of the U.S. Department of Energy's cold-climate heat pump challenge. Both list a quiet mode with up to three sound levels.
Like every heat pump, the FIT makes less heat as it gets colder. Our post on whether heat pumps work in Minnesota winters explains how to read those low-temperature numbers against your house.
Where does the Daikin FIT make the most sense?
The FIT makes the most sense where a cube-style condenser is hard to place:
- Narrow side yards between older houses in Minneapolis and Saint Paul, where a cube would block the only walkway. Our pages on heat pumps in Minneapolis and heat pumps in Saint Paul cover those older city houses.
- Townhomes and patio homes with a small slab or a tight corner.
- Walls. Daikin says the FIT can be wall-mounted when needed, which gets it off the ground entirely.
The catch is the side the air comes out of. Daikin's installation manual lets the intake side sit within a few inches of a wall, but its clearance drawings call for several feet of open space in front of the discharge side in most layouts, or the unit re-breathes its own air. Aiming it at a neighbor's garage wall a couple of feet away doesn't work. The manual's drawings decide the spot, and the installer should measure against them at the house before quoting.
FIT or a conventional heat pump, and when we'd skip the FIT
| Daikin FIT | Conventional cube-style heat pump | |
|---|---|---|
| Shape | Tall, shallow cabinet about a foot deep | Square cabinet with the fan on top |
| Airflow | In the back, out the side | In the sides, out the top |
| Narrow side yard | Fits if the discharge side has open space | Often blocks the walkway |
| Controls | Communicating system built around Daikin indoor equipment | Many work with a standard heat pump thermostat |
| Pairing with another brand's furnace | Ask how it would be controlled first | Usually the simpler add-on |
| Best fit | Tight lots, townhomes, wall mounts | Open yards and existing pads |
The FIT solves a space problem. If you don't have one, it isn't automatically the best heat pump for your house. A roomy backyard with a pad already in place can take a conventional cube-style heat pump without any of the clearance puzzles. A house that will keep a healthy non-Daikin furnace for another decade may be better served by a heat pump that pairs simply with a standard thermostat. And if the goal is heating a few rooms without ducts, a ductless mini-split is the better tool. We lay the options side by side when more than one fits.
Setting it up for a Minnesota winter
The FIT installation manual has a section for snowy locations, and it reads like it was written for here:
- Set the unit on a stand so the bottom frame sits more than 19¾ inches above the expected snow depth.
- Add a snow hood, and keep the unit out of spots where drifts pile up.
- Face the intake side toward the wall, or add a wind baffle, so wind doesn't blow straight into it.
- In locations that stay below 32°F for over 12 hours at a stretch, which covers much of a Minnesota winter, Daikin highly recommends the optional drain pan heater so defrost water can't freeze in the base.
- Don't tie the drain holes into a single pipe. It freezes.
The FIT Aurora handles the base differently: its spec sheet lists a hot-gas base pan that Daikin says eliminates the need for a separate drain pan heater down to 5°F. The stand and drift rules still apply.
What backup heat does the Daikin FIT pair with?
Daikin's FIT brochure shows it paired either with a Daikin air handler, where electric heat strips serve as the backup, or with a coil on a Daikin communicating gas furnace, which makes it a dual-fuel system. Because it is designed as a communicating system, the most straightforward installs use matched Daikin indoor equipment and the Daikin One+ thermostat. Our dual-fuel guide covers how the switchover point gets set either way.
Questions to ask on a FIT quote
- Which model is it, the standard FIT or the FIT Aurora, and what size?
- What's the indoor side: a Daikin air handler with electric strips, or a coil on a Daikin communicating furnace?
- What is the quoted model's heating capacity at 5°F, and how does it compare with the house's heat loss from the load calculation?
- Where exactly will it sit, and do the discharge clearances in Daikin's manual work at that spot?
- How high is the stand or bracket, and is a snow hood included?
- Is the drain pan heater included on a standard FIT?
- Who registers the warranty, and what maintenance does Daikin require to keep the unit replacement coverage?
The same questions apply to any heat pump, and our list of heat pump buying mistakes covers the ones people regret most.
Warranty, cost and next steps
Register it the week it goes in (Daikin's terms are in the FAQ below) and keep your maintenance records; ask us about a maintenance plan if you want the yearly visit on a schedule. For troubleshooting, the outdoor unit has a seven-segment display and stores fault codes, which helps a technician see what happened overnight.
Our installed price for a heat pump is $7,500–$14,500. Whether the FIT goes on a new Daikin air handler or a coil on a furnace, plus the line-set route and the stand or bracket, all shows up on the written quote. Our heat pump installation cost guide explains what moves a house up or down that range. We service and repair Daikin equipment and install it where it fits the house. If you have a narrow side yard and a tired air conditioner, call 612-429-3465 and we'll look at where a FIT, or a conventional heat pump, would actually go.
Common questions about heat pumps
Can a Daikin FIT go right next to the house?
The intake side can sit close to a wall, within the clearances in Daikin's installation manual. The side the air blows out of needs open space, several feet in most layouts, so the unit doesn't pull its own discharge air back in. Ask the installer to check the manual's drawings against your yard before quoting.
Does the FIT work with my existing furnace?
Daikin designs the FIT as a communicating system, and its brochure shows it paired with Daikin air handlers or with a coil on a Daikin communicating gas furnace. If your furnace is another brand, ask exactly how the FIT would be controlled with it before you buy. Sometimes a conventional heat pump is the simpler add-on.
What does the FIT warranty require?
Daikin's current spec sheets list a 12-year parts limited warranty and a 12-year unit replacement limited warranty, with online registration required within 60 days of installation. Daikin also lists annual maintenance requirements for the unit replacement coverage, so keep your service records and a copy of the registration confirmation.
How should a Daikin FIT be set up for Minnesota snow?
Daikin's installation manual calls for a stand that puts the bottom frame more than 19¾ inches above the expected snow depth, a snow hood, the intake side facing the wall or a wind baffle, and separate drain holes that are not piped together, since a shared pipe freezes. Daikin highly recommends the optional drain pan heater on the standard FIT.
